YIHUA-9936 Portable Soldering Station

Features
1. With the portable design, YIHUA-9936 portable soldering station weighs 500g or so, and is small in size. It is conveniently to take and operate.
2. It applies integrated design with high-efficient switching power supply and power control system. Controlled by the SAMSUNG microcomputer PID, it allows for fast warming. Only 15 seconds are required for the temperature rising from 30℃ to 300℃.
3. Both temperature and standby time are adjustable through the NC control. This equipment can real-time display the actual temperature.
4. The intelligent software design allows for automatic high temperature alarming, and automatic fault detection.
5. The YIHUA-9936 portable soldering station has a wide application range. It is suitable for the world-wide use. No power adapter is needed.

Parameters

Rated Voltage AC 220V±10% 50Hz
Output Power 10-40W
Dielectric Withstand Voltage Test AC1500V 0.4A 60S
Working Environment 0~40℃ relative humidity< 80%
Storage Environment -20~80℃ relative humidity< 80%
Overall Dimensions 13.5*5.2*3.2CM
Weight 0.5KG
Working Voltage AC 26V±10% 50Hz
Output Power 10-40W±10%
Temperature Range 200℃~480℃
Temperature Stability ±1℃ (Static)
Display Mode Red/green LED display
PID Temperature Correction Period 200ms
Heater Quality ceramic heater
Tip Ground Impedance < 2Ω
Tip of Ground Voltage < 2mV

Standard Configuration
Machine unit : 1set
Soldering iron handle (include iron tips and heater): 1pc
Iron holder: 1pc
Clean sponge: 1pc
Manual: 1pc
Power Plug: 1pc

Applications
YIHUA-9936 portable soldering station is suitable for the de-soldering and maintenance work of chip components, plug-in components, cables, and integrated components of the circuit board, in the electronic products production line, mobile phone repair industry, and precision electronic repair industry.

Related Names
Surface Mount Soldering Tool | Portable Soldering Iron | Electronic Desoldering Tool
