SMD Hot Tweezer Soldering Station, Item WEP-938D+

The hot tweezer soldering station comes with two soldering irons; you can either use an individual soldering iron or both simultaneously with different time settings. This is best fit for two operators due to the personalized design.

Parameters

Temperature Range 100°C~480°C/212°F~896°F
Display LCD
Temperature Stability ±2°C (Static)
Heating Coil Voltage AC 24V ±10% 50Hz
Tip to Ground Impedance <2Ω
Tip of Ground Voltage <2mV
dimension L150xW136xH93mm ±5mm
Wire Length ≥120cm
Working Temperature 0~40°C/32°F~104°F
Storage Temperature -20°C~80°C/-4°F~176°F
Storage Humidity 35%~45%
Features
  • Backlit LCD display with delicate design displays the accurate temperature of each soldering iron, as well as some other functions.
  • Personalized Functions:
    A.3-segment Parameter Storage Function:
    Memory function stores different parameters and allows for quick retrieval for future uses in three different temperature ranges: CH1/CH2/CH3.
    B. Interchangeable temperature display mode:
    Temperature display mode changes between Celsius and Fahrenheit according to different markets.
    C. Sleep Mode:
    The soldering rework station has status a self-detection function, if the equipment is in static motion for a set time, the system will go to sleep and the temperature of soldering iron will decrease to 100℃. This function can effectively prevent the soldering iron from oxidizing, which prolongs the lifespan as well saves energy.
    D. Auto Power-off Function:
    The system will count down once the machine is in sleep mode, if the rework station is not activated again in set time, the machine will automatically power-off to save energy.
    E. Temperature Correction Function:
    The rework station can automatically correct the temperature due to environmental changes or the replacement of the heating coil, solder iron or other components with a temperature correction range of -50℃ ~+50℃.
  • The touch interface adopts intelligent virtual buttons with excellent sensitivity, fast response, stable performance and delicate appearance.

Standard Configuration
Machine: 1pc
Soldering iron handle (including tip and heater): 2pcs
Titanium alloy holder: 1pc
Rosin flux: 1 box
Instruction book: 1pc
